Power Continuity
Cost Optimization
Flexible Integration
Easy Deployment | Model | M5 | M5S | M5C |
|---|---|---|---|
| Max. PV Array Power (kWp)@STC | 250 | / | / |
| Max. DC Voltage (V) | 1000 | / | / |
| MPPT Voltage Range (V) | 150~950 | / | / |
| Rated DC Voltage (V) | 600 | / | / |
| Start Voltage (V) | 180 | / | / |
| Max. DC Input Current (A) | 10 × 42 | / | / |
| Max. DC Short Circuit Current (A) | 10×60 | / | / |
| MPPT Number/Max. Input Strings | 10 / 20 | / | / |
| Model | M5 | M5S | M5C |
|---|---|---|---|
| Battery Type | LiFePO4 | LiFePO4 | LiFePO4 |
| Rated Energy (kWh) | 522 | 522 | 522 |
| Cell Cycle Life (70% EOL) | >8000 | >8000 | >8000 |
| Battery Round-trip Efficiency | ≥93.5% | ≥93.5% | ≥93.5% |
| Battery to AC Efficiency(@Rated Power) | ≥98.0% | ≥98.0% | ≥98.0% |
| Model | M5 | M5S | M5C |
|---|---|---|---|
| Rated Power (kW/kVA) | 250 / 250 | 250 / 250 | 250 / 250 |
| Rated Current (A) | 360 | 360 | 360 |
| Rated AC Voltage (V) | 380/400 | 380/400 | 380/400 |
| Rated Frequency (Hz) | 50 / 60 | 50 / 60 | 50 / 60 |
| On-Off-grid Switch Time (ms) | 0 | 0 | 0 |
| THDv (@ Linear Load) | <3% | <3% | <3% |
| Connection | 3+N+PE, Quick-plug Connector | 3+N+PE, Quick-plug Connector | 3+N+PE, Quick-plug Connector |
| Model | M5 | M5S | M5C |
|---|---|---|---|
| Input Configuration | Hybrid AC Input (Grid & Diesel Generator) | Single AC Input (Grid or Diesel Generator) | / |
| Rated Power (kW) | 125 | 250 | / |
| Rated Current (A) | 189.9/180.4 | 360 | / |
| Rated Voltage (V) | 3+N+PE, 380/400 | 3+N+PE,380/400 | / |
| Rated Frequency (Hz) | 50/60 | 50/60 | / |
| Model | M5 | M5S | M5C |
|---|---|---|---|
| Communication | Wi-Fi / Ethernet / CAN / RS485 | Wi-Fi / Ethernet / CAN / RS485 | Wi-Fi / Ethernet / CAN / RS485 |
| Operating Temperature Range (°C) | -20 ~ +50 | -20 ~ +50 | -20 ~ +50 |
| Operating Ambient Humidity (%) | 5–95 (No Condensing) | 5–95 (No Condensing) | 5–95 (No Condensing) |
| Cooling Method | Battery(Liquid Cooling), Inverter(Air Cooling) | Battery(Liquid Cooling), Inverter(Air Cooling) | Battery(Liquid Cooling), Inverter(Air Cooling) |
| Altitude (m) | ≤3000 | ≤3000 | ≤3000 |
| Ingress Protection | ≥C4 | ≥C4 | ≥C4 |
| Corrosion Protection | IP55 (Enclosure), IP66 (Inverter), IP66 (Battery) | IP55 (Enclosure), IP66 (Inverter), IP66 (Battery) | IP55 (Enclosure), IP66 (Inverter), IP66 (Battery) |
| Dimensions (L×W×H) (mm) | 3620×1903×1760 | 3170×1903×1760 | 3170×1903×1760 |
| Weight (kg) | 6,115 | 5813 | 5500 |
| Certification | CE, UN 38.3 | CE, UN 38.3 | CE, UN 38.3 |
